50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001

50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001
50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001
Basic Information
Place of Origin: LISHUI,ZHEJIANG
Brand Name: VERVO
Certification: API/CE/ISO
Model Number: Z61H-1500LB-DN50
Minimum Order Quantity: 10
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 1 week
Payment Terms: L/C, T/T, Western Union, D/A
Supply Ability: 40000pcs/month
Contact Now
Name: Forged Steel High Pressure 1500LB Gate Valve Media: Oli,Gas,Water
Standard: API602/BS5352/GOST/JIS/DIN/ISO Pressure: 150LB-800LB,1500LB,2500LB
Power: Manual,Pneumatic,Solenoid,Electrical Actuated Temperature Of Media: Medium Temperature,Normal Temperature,High Temperature,-65°F To 450°F (-54℃ To 232℃)
Size: 1/4"-4",DN8-DN100

50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve iSO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001



Quick Detail

50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 0
Model number Z61Y-1500LB-DN50
Item Forged Steel Solid Wedge Gate Valve
Certification ISO9001,ISO14001,ISO18001,TS,CE,API
Connection form FNPT,THREAD END
Body material Forged steel ASTM A182 F304
Purpose Sutiable for Various Industrise
Temperature -29-300




Forged Stainless Steel Gate Valve

50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 0

• Forged Stainless Steel Gate Valve
• Class 150/300/600/800/900/1500/2500/4500
• Reduced Port/Full Port
• Available in Forged (A105, LF2, F5, F11, F22, A182 F304 (L), F316 (L), F347, F321, F51,F53,F55,F60), Alloy 20, Monel, Inconel, Hastelloy,C95800
• ASME B16.34
• Maximum Pressure 1975 PSI
• Maximum Temperature 850
• Bolted Bonnet/Welded Bonnet/Pressure Seal Bonnet
• API 602 /BS5352/ API 598
• NACE MR0175
• Sizes 1/2” - 4”

Features and benefits

50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 2

TWO TYPES:

● This valve is available with an extended body or an integrally reinforcedextended body (IREB).
● Extended body gate valves have a welded or threaded connection and are used for tapping of pressure vessels and header lines for vents, drains or takeoff lines and instrumentation.
● Also available: extended body assemblies for vents, drains, and instrument root valves.



50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 3
CL800 Bolt Bonnet (BB)/Welding Bonnet (WB),
Reduce Port (RP)/Full Port (FP), Outside Screw and Yoke (OS&Y), Thread (NPT), Socket Weld (SW), Butt Weld (BW),
Size (NPS) R.P 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2
F.P 3/8 1/2 3/4 1 1-1/4 1-1/2 2
Face To Face L 79 92 111 120 120 140 178
Handwheel Diameter W 100 100 125 160 160 180 200
Height H 165 169 207 230 249 283 333
Flow Port Diameter d 10.3 13.5 18 23 29 36 45
Weight (Kg) B.B 2.2 2.4 4.1 5.5 7.5 10 19
W.B 2.1 2.3 4 5.5 7.3 9.5 18.5
50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 3
CL900~CL1500 Bolt Bonnet (BB)/ Welding Bonnet (WB),
Reduce Port (RP)/ Full Port(FP), Outside Screw and Yoke(OS&Y), Thread(NPT), Socket Weld(SW), Butt Weld(BW)
Size (NPS) R.P 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2
  F.P 3/8 1/2 3/4 1 1-1/4 1-1/2 2
Face To Face L 92 111 120 120 140 178
Handwheel Diameter W 100 125 160 160 180 200
Height H 169 207 230 249 283 333
Flow Port Diameter d 10.3 13.5 18 23 29 36
Weight (Kg) B.B 2.4 4.1 6.2 6.2 8.7 12.5
W.B 2.2 4 6 6 8.5 12
50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 5
CL2500 Welding Bonnet (WB),
Reduce Port (RP)/Full Port (FP), Outside Screw and Yoke (OS&Y),
Thread (NPT), Socket Weld (SW), Butt Weld (BW)
Size
(NPS)		 R.P 3/8 1/2 3/4 1 1-1/4 1-1/2 2
Face To Face L   120 120 120 140 178 178
Handwheel Diameter W   160 160 160 180 200 200
Height H   230 235 249 283 333 333
Flow Port Diameter d   10.3 13.5 18 23 29 36
Weight
(Kg)		 W.B   6.5 6.5 6.5 9 13 13



Keywords of 50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001

50mm Gate Valve Solid Wedge Gate Valve Forged Steel Valve ISO 15761 Socket Welded Gate Valves DN50 Gate Valve ISO 9001 6

High Pressure Gate Valve,Forged Steel BB Gate Valve, FNPT End Gate Valve, A105 Gate Valve, 2 Inch Gate Valve ,Class 1500 Gate Valve,API602 Gate Valve, BS5352 Gate Valve, 50mm BB Gate Valve,DN50 Gate Valve,FNPT End Gate Valve,Reduce Port Gate Valve,Solid Wedge Gate Valve,API602 Gate Valve,Stock Valve,Valve manufacture
